Linear Wood Panels with Batten for Acoustic Design

MCM Acoustical’s Linear Wood Panel with Batten is a natural wood veneered product available in a wide range of veneers and sizes. A felt mat can be provided at the back of the panel to improved acoustical performance.

Features

Dimensions:

The Panels can be manufactured to the desired size, with shop drawings produced by MCM Acoustical, thereby requiring no field cutting for faster installation. Blade width, height, length, and spacing can be customized.

Veneers:

The Linear Wood Panel with Batten can be customized in a variety of wood veneers. MCM Acoustical lays-up its own veneer random matched.

Finishes:

The Panels can be finished in standard clear lacquer or can be custom stained to match a control sample. The Linear Wood Panel with Batten can also be painted.

Performance Fire
Performance

The Linear Wood Panel with Batten are Class A Fire-Rated interior wood finish products as per ASTM E84 and CAN/ULC S102, and are tested in an accredited NVLAP test facility as a finished composite product using Class A individual components.

Acoustic Performance Acoustic
Performance

Linear Wood Panel with Batten are not perforated or grooved and are therefore reflective. If the project requires acoustic performance, please see our other acoustical products.

Acclimatization Acclimatization

Like any other architectural natural wood product, the Linear Wood Panel with Batten are to be acclimatized inside a controlled interior environment for at least 72 hours before installation. During storage, prior to
installation, during installation, and after installation the relative humidity level of 35%-55% and a temperature range of 20°-27°C (68°-81°F) must be maintained.

Sustainability Sustainability

FSC Certified
70.8% pre-consumer recycled content
Declare label
CDPH VOC Certified

Indoor Air Indoor Air
Quality

The Linear Wood Panel with Batten are certified Clean Air Gold and meet the CDPH Standard VOC emissions.

Finishes

Other Veneers are available upon request. If you wish to specify a wood species that is not mentioned on the finishes page, kindly contact MCM Acoustical to confirm its consistent availability. All veneers can be custom stained. Linear Wood Panel with Batten can be also painted.

Request Sample
